RPS 25HP 480V 300RPS250, Up to 325FT Head, 170 to 396GPM, Stainless Steel Submersible Pump End + Motor

Product image 1
1 / 14
+9

RPS 25HP 480V 300RPS250, Up to 325FT Head, 170 to 396GPM, Stainless Steel Submersible Pump End + Motor

The RPS Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.

✅  NSF Drinking Water and UL Compliant

Includes...

  • 25HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor End
  • 3" outlet 300RPS250 170-396GPM Pump End, 6" Outside Diameter
  • 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motor
  • Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire. Wires are not pre-crimped.

Customer Supplied Magnetic Starter Box.

Total Head Gallons Per Minute (GPM)
No head 396
25 feet 396
50 feet  396
75 feet 396
100 feet  396
125 feet  396
150 feet  389
175 feet  366
200 feet  340
225 feet 311
250 feet 270
275 feet 238
300 feet 203
325 feet 170
Above 325 feet  Size Up for Optimal Performance



The RPS Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.

✅  NSF Drinking Water and UL Compliant

Includes...

  • 25HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor End
  • 3" outlet 300RPS250 170-396GPM Pump End, 6" Outside Diameter
  • 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motor
  • Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire. Wires are not pre-crimped.

Customer Supplied Magnetic Starter Box.

Total Head Gallons Per Minute (GPM)
No head 396
25 feet 396
50 feet  396
75 feet 396
100 feet  396
125 feet  396
150 feet  389
175 feet  366
200 feet  340
225 feet 311
250 feet 270
275 feet 238
300 feet 203
325 feet 170
Above 325 feet  Size Up for Optimal Performance



$5,819.99
RPS 25HP 480V 300RPS250, Up to 325FT Head, 170 to 396GPM, Stainless Steel Submersible Pump End + Motor—
$5,819.99

Description

The RPS Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.

✅  NSF Drinking Water and UL Compliant

Includes...

  • 25HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor End
  • 3" outlet 300RPS250 170-396GPM Pump End, 6" Outside Diameter
  • 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motor
  • Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire. Wires are not pre-crimped.

Customer Supplied Magnetic Starter Box.

Total Head Gallons Per Minute (GPM)
No head 396
25 feet 396
50 feet  396
75 feet 396
100 feet  396
125 feet  396
150 feet  389
175 feet  366
200 feet  340
225 feet 311
250 feet 270
275 feet 238
300 feet 203
325 feet 170
Above 325 feet  Size Up for Optimal Performance
