RPS 20HP 480V 230RPS200, Up to 325FT Head, 148 to 317GPM, Stainless Steel Submersible Pump End + Motor

Product image 1
1 / 10
+5

RPS 20HP 480V 230RPS200, Up to 325FT Head, 148 to 317GPM, Stainless Steel Submersible Pump End + Motor

The RPS Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.

✅  NSF Drinking Water and UL Compliant

Includes...

  • 20HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor End
  • 3" outlet 230RPS200 148-317GPM Pump End, 6" Outside Diameter
  • 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motor
  • Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire. Wires are not pre-crimped.

Customer Supplied Magnetic Starter Box.

Total Head Gallons Per Minute (GPM)
No head 317
20 feet 317
30 feet  317
40 feet 317
50 feet  317
60 feet  317
70 feet  317
80 feet  317
90 feet  317
100 feet 317
110 feet 317
120 feet 317
130 feet 317
140 feet 317
150 feet 317
160 feet 317
170 feet 317
180 feet 308
190 feet 301
200 feet 291
210 feet 281
220 feet 267
230 feet 256
240 feet 245
250 feet 238
260 feet 224
270 feet 213
280 feet 205
290 feet 194
300 feet 185
310 feet 160
320 feet 148
Above 320 feet  Size Up for Optimal Performance



The RPS Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.

✅  NSF Drinking Water and UL Compliant

Includes...

  • 20HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor End
  • 3" outlet 230RPS200 148-317GPM Pump End, 6" Outside Diameter
  • 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motor
  • Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire. Wires are not pre-crimped.

Customer Supplied Magnetic Starter Box.

Total Head Gallons Per Minute (GPM)
No head 317
20 feet 317
30 feet  317
40 feet 317
50 feet  317
60 feet  317
70 feet  317
80 feet  317
90 feet  317
100 feet 317
110 feet 317
120 feet 317
130 feet 317
140 feet 317
150 feet 317
160 feet 317
170 feet 317
180 feet 308
190 feet 301
200 feet 291
210 feet 281
220 feet 267
230 feet 256
240 feet 245
250 feet 238
260 feet 224
270 feet 213
280 feet 205
290 feet 194
300 feet 185
310 feet 160
320 feet 148
Above 320 feet  Size Up for Optimal Performance



$5,209.99
RPS 20HP 480V 230RPS200, Up to 325FT Head, 148 to 317GPM, Stainless Steel Submersible Pump End + Motor—
$5,209.99

Description

The RPS Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.

✅  NSF Drinking Water and UL Compliant

Includes...

  • 20HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor End
  • 3" outlet 230RPS200 148-317GPM Pump End, 6" Outside Diameter
  • 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motor
  • Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire. Wires are not pre-crimped.

Customer Supplied Magnetic Starter Box.

Total Head Gallons Per Minute (GPM)
No head 317
20 feet 317
30 feet  317
40 feet 317
50 feet  317
60 feet  317
70 feet  317
80 feet  317
90 feet  317
100 feet 317
110 feet 317
120 feet 317
130 feet 317
140 feet 317
150 feet 317
160 feet 317
170 feet 317
180 feet 308
190 feet 301
200 feet 291
210 feet 281
220 feet 267
230 feet 256
240 feet 245
250 feet 238
260 feet 224
270 feet 213
280 feet 205
290 feet 194
300 feet 185
310 feet 160
320 feet 148
Above 320 feet  Size Up for Optimal Performance
