RPS 25HP 480V 400RPS250, Up to 225FT Head, 249 to 528GPM, Stainless Steel Submersible Pump End + Motor
The RPS Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.
✅ NSF Drinking Water and UL Compliant
Includes...
- 25HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor End
- 5" outlet 400RPS250 249-528 GPM Pump End, 8" Outside Diameter
- 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motor
- Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire. Wires are not pre-crimped.
Customer Supplied Magnetic Starter Box.
| Total Head | Gallons Per Minute (GPM) |
| No head | 528 |
| 10 feet | 528 |
| 20 feet | 528 |
| 30 feet | 528 |
| 40 feet | 528 |
| 50 feet | 528 |
| 60 feet | 528 |
| 70 feet | 528 |
| 80 feet | 510 |
| 90 feet | 482 |
| 100 feet | 453 |
| 110 feet | 419 |
| 120 feet | 370 |
| 130 feet | 317 |
| 140 feet | 274 |
| 150 feet | 389 |
| 160 feet | 353 |
| 170 feet | 341 |
| 180 feet | 305 |
| 190 feet | 285 |
| 200 feet | 264 |
| Above 200 feet | Size Up for Optimal Performance |
The RPS Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.
✅ NSF Drinking Water and UL Compliant
Includes...
- 25HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor End
- 5" outlet 400RPS250 249-528 GPM Pump End, 8" Outside Diameter
- 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motor
- Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire. Wires are not pre-crimped.
Customer Supplied Magnetic Starter Box.
| Total Head | Gallons Per Minute (GPM) |
| No head | 528 |
| 10 feet | 528 |
| 20 feet | 528 |
| 30 feet | 528 |
| 40 feet | 528 |
| 50 feet | 528 |
| 60 feet | 528 |
| 70 feet | 528 |
| 80 feet | 510 |
| 90 feet | 482 |
| 100 feet | 453 |
| 110 feet | 419 |
| 120 feet | 370 |
| 130 feet | 317 |
| 140 feet | 274 |
| 150 feet | 389 |
| 160 feet | 353 |
| 170 feet | 341 |
| 180 feet | 305 |
| 190 feet | 285 |
| 200 feet | 264 |
| Above 200 feet | Size Up for Optimal Performance |
Original: $5,629.99
-65%$5,629.99
$1,970.50Description
The RPS Steel Flow line of pumps is perfect for any industrial, agriculture, pond or orchard project needing high gallon per minute flow rates. Pumps are fully stainless steel.
✅ NSF Drinking Water and UL Compliant
Includes...
- 25HP Three phase, 480V, 3 wire (3+G), 6" Diameter Motor End
- 5" outlet 400RPS250 249-528 GPM Pump End, 8" Outside Diameter
- 3 Wire (3 Hot + Ground) w/ 6 foot pigtail of 10 gauge wire off the motor
- Back 40 Crystal Clear Splice Kit for connecting pigtail to more submersible pump cable w/ four crimps and four crystal clear shrink tubing. Special larger crimps are included to accommodate up to 8Ga wire. Wires are not pre-crimped.
Customer Supplied Magnetic Starter Box.
| Total Head | Gallons Per Minute (GPM) |
| No head | 528 |
| 10 feet | 528 |
| 20 feet | 528 |
| 30 feet | 528 |
| 40 feet | 528 |
| 50 feet | 528 |
| 60 feet | 528 |
| 70 feet | 528 |
| 80 feet | 510 |
| 90 feet | 482 |
| 100 feet | 453 |
| 110 feet | 419 |
| 120 feet | 370 |
| 130 feet | 317 |
| 140 feet | 274 |
| 150 feet | 389 |
| 160 feet | 353 |
| 170 feet | 341 |
| 180 feet | 305 |
| 190 feet | 285 |
| 200 feet | 264 |
| Above 200 feet | Size Up for Optimal Performance |
